{{ tags.important.name }}Tri-Ring 4×4 Off-Road Dump Truck (160HP)

Product Introduction

The Tri-Ring 4×4 Off-Road Dump Truck is a rugged, all-wheel-drive commercial vehicle engineered to perform in the most unforgiving environments. Built specifically for mining, construction, and extreme material hauling in harsh terrains, this chassis combines robust engine reliability with premium heavy-duty off-road axles, making it a highly capable asset for operations where standard trucks would fail.

Powertrain and Performance

Powering this off-road workhorse is the reliable Yuchai YC4E160-33 diesel engine, delivering a solid 160HP. The engine is seamlessly mated to a heavy-duty FAST 8JS85TM 8-speed manual gearbox, ensuring smooth power transmission and exceptional durability under severe load conditions. Compliant with Euro 2 emission standards, this highly durable mechanical configuration is specifically tailored for export markets where fuel quality varies and ease of maintenance is prioritized over modern emission compliance.

Chassis Architecture and Payload

What truly sets this vehicle apart is its drivetrain. It features a true 4×4 all-wheel-drive system equipped with Hub Reduction axles on both the front (3T) and rear (8T), paired with a steep 5.92 rear axle ratio. This premium off-road technology significantly increases ground clearance and multiplies torque at the wheels, making the truck highly capable in deep mud, mining pits, and steep off-road grades. It rides on a 4,200 mm wheelbase with a robust 230 (6+5) frame and durable 8.25R16-16 tires. With a curb weight of 4,400 kg and a 16,000 kg Gross Vehicle Weight (GVW), it delivers a legal payload capacity of 11.6 tons. A 160 L aluminum alloy fuel tank ensures extended operating range in remote locations.

Cabin and Driver Comfort

The vehicle is equipped with a practical T3 (1995 mm width) Standard Single Cab with a flat roof. Designed for maximum functionality, it comes standard with air conditioning and ABS (Anti-lock Braking System), ensuring a safe and comfortable working environment despite the extreme external conditions.

Global Export and EFON GROUP Partnership

As the authorized global export agent, EFON GROUP is dedicated to delivering premium commercial vehicles to international markets across Africa, Southeast Asia, Latin America, and the Middle East. We provide comprehensive end-to-end export solutions, including customized bodywork coordination, rigorous pre-shipment quality inspections, and reliable sea freight logistics. By choosing EFON GROUP, international buyers secure a trusted partner committed to competitive pricing, seamless global shipping, and dedicated after-sales support for their entire fleet.

• Drive & Axles: This is a rugged 4×4 all-wheel-drive dump truck. It is equipped with Hub Reduction Axles (轮减桥) on both the front (3T) and rear (8T), paired with a steep 5.92 rear axle ratio. This setup significantly increases ground clearance and multiplies torque at the wheels, making it highly capable in mud, mining pits, and steep off-road grades.
• Engine & Drivetrain: Powered by the reliable Yuchai YC4E160-33 (160HP) engine and a heavy-duty FAST 8JS85TM 8-speed manual transmission.
• Payload Capacity: With a GVW of 16,000 kg and a curb weight of 4,400 kg, the legal payload capacity is 11.6 tons.
• Export Note: The Euro 2 standard and the highly durable mechanical configuration indicate this vehicle is specifically tailored for export markets (such as Africa, Southeast Asia, or Latin America) where fuel quality varies and extreme durability is prioritized over modern emissions compliance.
